Polygonal 3mm 30 FT Electrical Power Pole 220KV Transmission Line Poles

Large Image : Polygonal 3mm 30 FT Electrical Power Pole 220KV Transmission Line Poles

Product Details:

Place of Origin:	China
Brand Name:	MilkyWay
Certification:	ISO9001/BV/
Model Number:	Electric Steel Power Pole

Payment & Shipping Terms:

Minimum Order Quantity:	1 pcs
Price:	Negotiation
Packaging Details:	As customer request
Delivery Time:	20 working days after received your payment
Payment Terms:	T/T, L/C at sight
Supply Ability:	300pcs per day

Contact Now

Detailed Product Description

Product Name:	Electric Power Pole	Power:	220KV
Material:	Gr65	Surface Treatment:	Hot Dip Galvanization
Welding Standard:	AWS D 1.1	Life Time:	50 Years
Highlight:	metal power poles , steel utility poles

Polygonal 3mm 30FT Electric Steel Pole with Galvanization and Bitumen

Specifications:

Philippines NPC Specification
ITEM	STEEL POLE
	TYPE	LENGTH	TIP DIAMETER	BUTT DIAMETER	THICKNESS
	TYPE	(FT)	(MM)	(MM)	(MM)
1	B	50	200	370	6
2	E	50	200	585	6
3	HT	50	200	520	6
4	B	55	200	395	6
5	E	55	200	625	6
6	HT	55	200	550	6
7	B	60	200	415	6
8	C	60	250	730	6
9	D	60	300	765	7
10	E	60	200	660	6
11	HS	60	200	400	6
12	HT	60	200	580	6
13	B	65	200	435	6
14	C	65	250	770	6
15	D	65	300	755	8
16	E	65	200	700	6
17	HT	65	200	615	6
18	B	70	200	455	6
19	C	70	250	805	6
20	D	70	300	790	8
21	E	70	200	740	6
22	HT	70	200	645	6
23	3T	70	250	640	6
24	3D	70	300	765	6
25	spare type D	70	300	790	8

The information to inquiry or purchase
-Steel pole height and force
-Cross arm type and length,the position to install in the steel pole
-The method to fix the cross arm(use bolt to connect or use one or two template to weld in the steel pole to install the cross arm)
-Safety factor of the steel pole
-Wind speed
-Type of climbing rung
-Destination port
-Other.
Technical information-Cross Arm

Inspection
To assure our products qualified ,we take steps as follows :
1. Management team : We have employ the foreign export to take chaege of the overall managemnt,especailly the technical managemnt and quality management .
2.Introducing ISO management ,We are awared ISO 9001:2008 certificate . .
3.QC Inpection:It is our company policy that all the finish product should be inspected by our specialzed QC in every manufacure steps and beofore every shipment

Polygonal 3mm 30 FT Electrical Power Pole 220KV Transmission Line Poles 0

Company Introduction:
Jiangsu Milky Way Steel Poles which established on 1991 is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .
Our Company has 24 years experience on producing the steel poles including the transmission power pole,street light pole,high mast pole and so on.
We exported to oversea countries since 1991 and our products have been delivered to more than 70 countries and areas ,including America,Australia ,Russia ,Germany ,Span,Philippines ,Malaysia,Africa and so on.
We are the supplier of many big project in many countries,like the street light pole of Dubai Tower.the high mast pole for Sochi Winter Olympic Game and so on.

Polygonal 3mm 30 FT Electrical Power Pole 220KV Transmission Line Poles 1

FAQ

1. Price Term: EXW, FOB, CFR or CIF.
The price includes pole shaft, base plate, cross arm and anchor part.
Shipping seaport: Shanghai Seaport. For FOB, CFR or CIF price, please specify which exact model you need, and tell us your order quantity so that we can calculate the local transport charges and sea freight.
2. MOQ: 1 sets for Customized
3. Payment: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.
4. Delivery time : goods can be ready for shipment within 10 workdays after receiving deposit.
5. Warranty : 30 years
6.Surface treatment :hot dip galvanization
